.NetDisk NDAS(Network Direct Attached Storage) NetDisk User Manual Ximeta Technology www.ximeta.com.Warranty License Main Features of NetDisk Different NetDisk Mode Application NDAS Mode Ethernet Mode USB2.0 Portable Mode NetDisk Models Covered By This Guide Package Contents Chapter 2 Requirements Hardware Requirement NDAS Mode Usage Ethernet Mode Usage USB2.0 Mode Usage Software Requirement.Congratulations on your purchase of the NetDisk Network Direct Attached Storage Solution. This NetDisk User Manual is intended to help you install the product quickly and easily. The NetDisk Installation Guide is intended for individual users who need to install and support one or more NetDisk on their PC’s or Ethernet network.With NDAS mode, NetDisk is directly attached to 100BaseT full duplex switching hub, and each user in the network can use NetDisk as a local disk drive. In addition, each and every user can easily enjoy all of the advanced NDAS features such as mirroring, aggregation, and flexible expansion.NetDisk NDAS(Network Direct Attached Storage) Package Contents The following items are included in the NetDisk package: NetDisk Quick Install Guide Software Installation CD-ROM Ethernet Cable USB Cable Power Adapter and Power Cord XiMeta, Inc www.ximeta.com.Cross-over LAN cable (not included) USB2.0 Mode Usage PC with USB port Software Requirement The NetDisk Administration software V.1x only supports Windows 2000 and Windows XP. Windows 2000 or XP users may need to install USB2.0 driver which is included in the installation CD.Simply follow step by step instructions and complete the installation.

1. Netdisk Ndas Software

For The First Time Users The NetDisk is unique and it is the world’s first NDAS system. NetDisk is the world’s first Ethernet and USB combination external HDD. It is strongly recommended for the first time NetDisk users to select easy installation from the main menu.For Advanced Users Once you get comfortable installing or using NetDisk, you do not need to follow the User Guide. Simply click “Advanced user installation” to skip step by step installation instructions.Chapter 4 NetDisk™ Administrator Once you complete your software installation, you will find a NetDisk launcher icon on your desktop screen and a NetDisk Administrator Tool icon on the bottom right corner of the system tray. Using the NetDisk Administrator Tool, each NetDisk needs to be registered before it can be used.If the Write Key was entered in the previous step, the NetDisk is registered as Read/Write Mode. If the Write Key was not entered in the previous step, the NetDisk is registered as Read Only Mode. Action window.Please select one of the choices from the below.

O If you do not want the window to appear every time a NetDisk is registered/added/enabled, select Take no action and the box Always do the same action.NetDisk in Read Only Mode, indicated by Green circle. Installation of New NetDisk Every time a new NetDisk is added, it must be registered into your computer. Found New Hardware Wizard will automatically register the new NetDisk with a click of a button. Please refer to instructions below.If you click STOP Installation, NetDisk’s Device Drivers will not get installed and one cannot use the NetDisk. If you want to re-install the NetDisk, please follow the Re-Install NetDisk in step one of this section.

XiMeta, Inc www.ximeta.com.NetDisk provides users with seven basic Modes. When a user first registers his/her NetDisk, it is either registered in as a Read Only Mode or Read/Write Mode. Once the NetDisk is successfully registered with either of the two Modes, user can change the Mode of the NetDisk or perform advanced functions, such as aggregation or mirroring. You can only remove it from your computer or view its property.

NetDisk Administrator Tool Menu Click NetDisk™ Administrator Tool. All the registered NetDisk will be displayed on the NetDisk Administrator Tool Menu. XiMeta, Inc www.ximeta.com.B. Refresh Status - Updates the status of NetDisk that are connected to the network. NOTE: If a NetDisk is displayed by a Black colored circle, it means network cable or power cable of the NetDisk is disconnected.

This will cause operations of other NetDisk to slow down.Click NetDisk Administrator Tool and place the cursor on one of the NetDisk to view its functions. Each of the NetDisk Modes has its own distinguished functions.

Please refer to the diagram on the next page. Displays functionality of each NetDisk Mode.B. Edit Name - Changes the name of the NetDisk. Type in the new name for the NetDisk on Edit a NetDisk window then click OK. If you do not want to change the name of the NetDisk, simply click Cancel.C. Oblivion crack deutsch. Enable Read Only - Enables you back into Read Only Mode.

Enable Read/Write - Enables you back into Read/Write Mode. Sometimes a NetDisk cannot enable the write access because the NetDisk is busy with other applications or another user.

In such a case, NetDisk Administrator window will appear.NetDisk Administrator appears when you select remove. Click OK if you want to remove the NetDisk.

Otherwise, click Cancel. Change from Read Only Mode to Read/Write Mode The following instructions guide a user in changing NetDisk’s Mode (from Read Only to Read/Write). Click NetDisk Administrator Tool and select a NetDisk you want to change.NOTE: The Add button will only be enabled when the correct Write Key is entered. Occasionally, a NetDisk cannot enable the write access because the NetDisk is busy with other applications or another user. In such a case, NetDisk Administrator window will appear.NOTE: Sometimes the color of the circle changes to White instead of Gray. This indicates that NetDisk is busy.

Please wait until later time or enable the NetDisk back to Read Only Mode.NetDisk Message appears on the screen, NetDisk Administrator window will appear. Click OK then please try it at later time. If the current writer accepts the request and passes on the write access, NetDisk Administrator window will not appear. XiMeta, Inc.13. New writer’s NetDisk circle icon will be change from Green to Blue, indicating a Read/Write Mode. NOTE: Give few seconds for the color of the NetDisk to be updated.

If the color of the NetDisk you changed is still Green, repeat from step 1 again.3. Click NetDisk™ Administrator Tool to view the changed NetDisk. NOTE: Give few seconds for the color of the NetDisk to be updated. If the color of the NetDisk you changed is still Blue, repeat from step 1 again. XiMeta, Inc.Aggregation is one of the two advanced features NetDisk provides. Aggregation allows users to enable multiple NetDisk units to be recognized as a single large disk drive.

This feature is extremely useful where a larger storage device is needed. Please follow the steps below to aggregate NetDisk.NetDisk you want to disable and then select Disable. NetDisk Administrator. If the NetDisk you selected is in use by any applications, NetDisk will not be disabled. In such case, wait until all the applications are finished using NetDisk. Then try disabling it again.NOTE: Disabled NetDisk will be indicated by Gray colored NetDisk.

Give few seconds for the changes to take place. If the color of the disabled NetDisk has not been changed to Gray, click Status.

Netdisk Ndas Software

If the color still has not changed, repeat steps 2 and 3 for every NetDisk that did not get disabled.B. If NetDisk you selected has a Write Key, the Bind window will appear. Aggregation: The NetDisks bound box on the right, indicates the first NetDisk you select to bind. The NetDisks Available box on the left, lists all the NetDisk you can select from to bind with the first NetDisk.NetDisk NDAS(Network Direct Attached Storage) 11. Select a NetDisk from the NetDisk Available box that you want to bind/mirror to. Once you selected a NetDisk, click button.

If NetDisk you selected from NetDisks Available box does not have a Write Key AggrMirUI will appear.NetDisk and take you back to step 11. For mirroring only. Warning Message. If a NetDisk you are mirroring the data to is smaller than the NetDisk you are mirroring the data from, warning window will appear. Click OK.The NetDisk from the NetDisks bound box becomes the Master NetDisk and the NetDisk from the NetDisks available box becomes the Slave NetDisk. The slave gets added to the master NetDisk. The name Master NetDisk 1 is Master plus the name of the first NetDisk.NOTE: NetDisk 1 is disabled master NetDisk and NetDisk 3 is slave NetDisk.

Enable the bound/mirrored NetDisk by selecting either Enable Read/Write or Enable Read Only. Go to NetDisk Aggregation & Mirroring window.

You will notice the changes in the color of the master NetDisk. Aggregation XiMeta, Inc www.ximeta.com.Please refer to Partition NetDisk on page 39. Unbind In order to unbind a NetDisk all the users who have the bound NetDisk registered in their computer must disable the NetDisk.

NetDisk cannot be unbound until it is disabled from all the users’.NOTE: You can only unbind disabled NetDisk. NetDisk Administrator. If the NetDisk is being used by any applications, NetDisk will not be disabled. In such case, wait until all the applications are finished using NetDisk. Then try disabling it again.NetDisk NDAS(Network Direct Attached Storage) Go to NetDisk Aggregation & Mirroring window. The color of the master NetDisk you just disabled will be Gray. If not, press Status button.

Select a NetDisk you want to unbind and click unbind button.Mirroring is another advanced feature NetDisk provides beside aggregation. The purpose of mirroring is to continuously create and save a copy of data in one NetDisk to another NetDisk, in real time, whenever a new data is written to the NetDisk. Please refer to the below instructions.Please follow the Aggregation - Unbind on page 32 to undo Mirroring. Chapter 6 Uninstallation Uninstall NetDisk Before you can uninstall the NetDisk, you must close all the applications that are using the NetDisk.

NOTE: NetDisk Administrator, NetDisk Aggregation & Mirroring, Windows Explorer and Internet Explorer must be closed.If not, you will have problem re-installing the NetDisk Software. Click Start Control Panel Add or Remove Programs NetDisk Remove A. Add or Remove Programs will appear. Click Yes if you want to continue uninstall.If not, you will have problem re-installing the NetDisk Software.

NOTE: Problem Ejecting NetDisk appears when applications are using the NetDisk you are trying to remove. Click OK and try removing the NetDisk again after a few minutes. XiMeta, Inc www.ximeta.com.NetDisk NDAS(Network Direct Attached Storage) Chapter 7 Formatting NetDisk Partition NetDisk 1.

Right click My Computer and select Manage. Computer Management will appear. Click Disk Management under Storage. XiMeta, Inc www.ximeta.com.NetDisk NDAS(Network Direct Attached Storage) 3. Disabled disk will be shown on the Computer Management. Right click on the box and select Delete Partition. Delete primary partition will appear.

NOTE: When you delete partition, all the data on the disk will be last.NetDisk NDAS(Network Direct Attached Storage) 6. Partition has been deleted and it is indicated by the word Unallocated.

Right click on the box and select New Partition. New Partition Wizard: Click next. XiMeta, Inc www.ximeta.com.NetDisk NDAS(Network Direct Attached Storage) 9. Select Partition Type: Select Primary partition and click Next. Specify Partition Size: Click Next. NOTE: The partition size is automatically set. No need to change the size.

Assign Drive Letter or Path: Select Assign the following driver letter and choose a name for the drive from list.NetDisk NDAS(Network Direct Attached Storage) 12. Format Partition: Select Format this partition with the following Settings and Perform a quick format (Recommended). Click next. Partitioning is finished. Click Finish.

You can see the partitioned disk. XiMeta, Inc.NetDisk NDAS(Network Direct Attached Storage) Initialize NetDisk 1. Right click My Computer and select Manage. Computer Management window will appear. Click Disk Management under Storage.

Computer Management window will list all the disks in the computer. XiMeta, Inc www.ximeta.com.Find NetDisk you want to format and right click NOTE: NetDisk you are looking for is the unknown or not initialized disk. Select Initialize NetDisk. Initialize NetDisk window will appear. Select the right disk and click Ok. NetDisk will be automatically initialized.NetDisk NDAS(Network Direct Attached Storage) NOTE: Unknown becomes Basic 6. Right click Unallocated box then select New Partition.

Go to Partition NetDisk on 39 and start from step 8. XiMeta, Inc www.ximeta.com.15251 Alton Parkway Irvine, CA 92618 What to do before you contact us: Whenever you contact XiMeta, Inc. For technical support, please have the following information available: Product name, model, serial number and software version number. Technical Support on the Internet: For the latest information on NetDisk, visit our website at www.ximeta.com.
